Sub-miniature

connectors

No compromises in quality.

These subminiature M9 connectors are available with 2 to 8 contacts for panel mounting or as cable connectors with moulded versions.

Features:

Both versions are shieldable
Cable connectors feature solder termination
Panel mount versions are available with solder and dip solder termination
Degree of protection is IP67 with an operating temperature range is -40°C to +85°C.

Read more about binder's programme.

Miniature M16 IP40 connectors

The M16 connectors of the 581, 680 and 682 series according to DIN EN 61076-2-106 are available with 2 to 24 contacts with crimp, dip solder, screw clamp, solder and stranded wire connection.

Options:

Available as straight and angled cable versions or flange versions.
Many versions are shieldable.
Depending on the number, the contacts are designed for a rated current of 1 A to 7 A

Read more about binder's programme.

Power connectors

A range of power connectors suitable for virtually any low and high voltage application, from security and CCTV systems to fieldbus Ethernet components and AC and DC motors.

Some models meet the requirements of the most extreme environments - both indoor and outdoor.

Various connection options are available:

bayonet
M25
D24 locking systems
Some models are ESTI+, UL and VDE approved.
To expand the range of applications: choose between straight and right-angled cable and flange versions.

Read more about binder's programme.

Connectors for medical applications

MedTech connectors made of high-quality materials in the quality and reliability required in this particular field.

Standard in grey-white but other colours can be ordered.

Features:

Snap-in and bayonet locking
Up to 5,000 mating cycles
IP54 and IP67
3 to 12 poles
Solder and dip solder connections
High quality materials
ISO 13485 certified company
Clearance and creepage distances available on request
Disinfectant resistance (see brochure connectors for medical applications)
Biocompatibility (DIN EN ISO 10993-5)
FDA-compliant for aqueous foodstuffs according to regulation EG596/2009
DEHP-free (except contacts)
DIN EN 60601-11 Shock and vibration test
DIN EN 60601-1 Drop test

Read more about binder's programme.

Automation technology - sensors and actuators

Connector systems for sensors and actuators in many lines of industry.

Features:

From IP40 to IP69K
Many with UL, VDE and Ecolab approval, as well as FDA compliant models.
Circular connectors with 2 to 12 contacts
Various termination options, including solder, crimp, dip solder, cable and stranded wire termination.
Connectors with M5, M8 and M12 screw locking are available in straight and angled and flanged versions.
In addition to duo connectors and dual distributors, a wide range of connecting cables is also available.

Read more about binder's programme.

Automation technology - data transmission

7 different circular connectors for signal and data transmission in modern, automated factories. These are mainly M8, M12, M16 circular connectors that can be configured.
For data transmission a shielded, X-coded M12 connector can handle data transfer rates up to an impressive 10 Gbit/s.

Features:

6 product series
Various locking systems, including M8, M12 and M16
Coding, including M12 - B, -D and -X
Protection class from IP20 to IP69K
2 to 8 contacts
Shielded and shieldable
PUR- and PVC cables
Cable lengths from 0.5 m to 10 m

Read more about binder's programme.

Automation technology - voltage and power supply

Power connectors used to supply AC motors, drives and motor switches with high voltages over longer periods of time. Also for low-voltage applications such as fieldbus Ethernet components and network devices. This series is mainly M12, M18 and 7/8 inch circular connectors that can be configured. The M12 connectors with K and S coding can be used up to a rated voltage of 630V AC.

Features:

9 product series
Various locking systems, including M12, M18 and 7/8".
Coding, including M12 - S, -K, -T, -L and -US
Protection class from IP20 to IP69K
2 to 8 contacts, including 2+PE, 3+PE and 4+PE
Shielded and shieldable
PUR and PVC enclosures
Cable lengths from 0.5 m to 10 m

Read more about binder's programme.

binder - the German connector brand

Absolute reliability and responsibility

binder and Mikkelsen have been partners from the very start of Mikkelsen Electronics.

Due to a wide variety of quality connectors binder has been the optimum choice for decades.
